TYPE:
S.S. WELDED TUBES:
Outer Dimeter: 6.00 mm to 406.4 mm
S.S. WELDED PIPES:
Outer Diameter: 1/8" NB to 24" NB
Thickness: Available in all Schedule Sizes
S.S. SEAMLESS TUBES:
Outer Diameter: 6.00 mm to 114.3 mm
Thickness: 0.45 mm to 6.0 mm
S.S. SEAMLESS PIPES:
Outer Diameter: 1/8" NB to 16" NB
Thickness: Available in all Schedule Sizes
MATERIAL: STAINLESS STEEL GRADE:
202, 304, 304L, 310, 316, 316L, 316TI, 317, 317L, 321, 904L, DUPLEX UNS S32205/31803, SUPER DUPLEX UNS S32750 etc.
SPECIFICATION: ASTM, A-213, A-249, A-268, A-269, A-270, A-312, A-358, A-409, A-554, A-688, A-778, A-789, A-790, A-928.
Nominal Pipe Size |
Outside Diameter |
Schedule 5 S |
Schedule 10 S |
Schedule 20 S |
Schedule 40 S |
Schedule 80 S |
Schedule 160 S |
XXS |
||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
mm |
inch |
inch |
Wt mm |
Weight (KGM) |
Wt mm |
Weight (KGM) |
Wt mm |
Weight (KGM) |
Wt mm |
Weight (KGM) |
Wt mm |
Weight (KGM) |
Wt mm |
Weight (KGM) |
Wt mm |
Weight (KGM) |
3 |
1/8 |
10.3 |
1.2 |
0.26 |
1.24 |
0.28 |
1.5 |
0.33 |
1.73 |
0.37 |
2.41 |
0.47 |
|
|
|
|
6 |
1/4 |
13.7 |
1.2 |
0.37 |
1.65 |
0.49 |
2.00 |
0.53 |
2.24 |
0.63 |
3.02 |
0.80 |
|
|
|
|
10 |
3/8 |
17.1 |
1.2 |
0.47 |
1.65 |
0.63 |
2.00 |
0.74 |
2.31 |
0.84 |
3.20 |
1.10 |
|
|
|
|
15 |
1/2 |
21.3 |
1.65 |
0.80 |
2.11 |
1.00 |
2.30 |
1.07 |
2.77 |
1.27 |
3.73 |
1.62 |
4.78 |
1.94 |
7.47 |
2.55 |
20 |
3/4 |
26.7 |
1.65 |
1.02 |
2.11 |
1.28 |
2.55 |
1.52 |
2.87 |
1.69 |
3.91 |
2.20 |
5.56 |
2.90 |
7.82 |
3.64 |
25 |
1 |
33.4 |
1.65 |
1.30 |
2.77 |
2.09 |
3.00 |
2.25 |
3.38 |
2.50 |
4.55 |
3.24 |
6.35 |
4.24 |
9.09 |
5.45 |
32 |
1.1/4 |
42.2 |
1.65 |
1.65 |
2.77 |
2.70 |
3.00 |
2.90 |
3.56 |
3.39 |
4.85 |
4.47 |
6.35 |
5.61 |
9.70 |
7.77 |
40 |
1.1/2 |
48.3 |
1.65 |
1.90 |
2.77 |
3.11 |
3.00 |
3.35 |
3.68 |
4.05 |
5.08 |
5.41 |
7.14 |
7.25 |
10.15 |
9.55 |
50 |
2 |
60.3 |
2.11 |
2.39 |
2.77 |
3.93 |
3.00 |
4.24 |
3.91 |
5.44 |
5.54 |
7.48 |
8.74 |
11.11 |
11.07 |
13.44 |
65 |
2.1/2 |
73.0 |
2.11 |
3.69 |
3.05 |
5.26 |
4.00 |
6.81 |
5.16 |
8.63 |
7.01 |
11.41 |
9.53 |
14.91 |
14.02 |
20.39 |
80 |
3 |
88.9 |
2.11 |
4.51 |
3.05 |
6.45 |
4.00 |
8.37 |
5.49 |
11.29 |
7.62 |
15.27 |
11.10 |
21.30 |
15.24 |
27.68 |
100 |
4 |
114.3 |
2.11 |
5.84 |
3.05 |
8.36 |
4.50 |
12.16 |
6.02 |
16.07 |
8.56 |
22.32 |
13.49 |
33.54 |
17.12 |
41.03 |
125 |
5 |
141.3 |
2.77 |
9.47 |
3.40 |
11.57 |
5.00 |
16.80 |
6.55 |
21.80 |
9.53 |
30.97 |
15.88 |
49.11 |
19.05 |
57.43 |
150 |
6 |
168.3 |
2.77 |
11.32 |
3.40 |
13.82 |
6.35 |
25.86 |
7.11 |
28.26 |
10.97 |
42.56 |
18.25 |
67.53 |
21.95 |
79.22 |
200 |
8 |
219.1 |
2.77 |
14.78 |
3.76 |
19.96 |
6.35 |
33.31 |
8.18 |
42.55 |
12.70 |
64.64 |
23.01 |
111.27 |
22.23 |
107.92 |
250 |
10 |
273.1 |
3.40 |
22.61 |
4.19 |
27.78 |
6.35 |
41.77 |
9.27 |
60.31 |
12.70 |
81.55 |
28.58 |
172.33 |
25.40 |
155.15 |
300 |
12 |
323.8 |
3.96 |
31.24 |
4.57 |
36.00 |
6.35 |
49.70 |
9.53 |
73.85 |
12.70 |
97.43 |
33.32 |
238.68 |
25.40 |
186.90 |
350 |
14 |
355.6 |
3.96 |
34.34 |
4.78 |
41.3 |
7.92 |
67.90 |
9.52 |
82.367 |
|
|
|
|
|
|
400 |
16 |
406.4 |
4.19 |
41.56 |
4.78 |
47.34 |
7.92 |
77.82 |
9.52 |
94.457 |
|
|
|
|
|
|
450 |
18 |
457.2 |
4.19 |
46.81 |
4.78 |
53.32 |
7.92 |
87.74 |
9.52 |
106.547 |
|
|
|
|
|
|
500 |
20 |
508.0 |
4.78 |
59.31 |
5.54 |
68.64 |
9.53 |
117.14 |
9.52 |
118.638 |
|
|
|
|
|
|
600 |
24 |
610.0 |
5.54 |
82.57 |
6.35 |
94.52 |
9.53 |
114.11 |
- |
- |
|
|
|
|
|
|
